NCAS1000MP
Please note: This product is expected in 2025
The NCAS1000MP amplifier power brick boasts a groundbreaking design featuring two distinct amplification channels, a full-bridge high-power channel and a half-bridge medium-power channel. This dual-channel architecture is tailored to cater to different audio requirements, providing a comprehensive solution for active loudspeaker designs.
The full-bridge 800W high-power channel is engineered for robust performance, delivering an impressive power output suitable for driving the low-frequency drivers with high efficiency. This channel excels in handling demanding audio signals, ensuring clarity and precision in reproducing the full spectrum of sound. It is the powerhouse of the module, where high output and dynamic range are paramount.
Complementing the high-power channel, the half-bridge 200W medium-power channel is designed for versatility. It offers a balanced mix of power and efficiency, making it well-suited for driving secondary drivers, such as tweeters or full-range drivers. This channel is optimized to handle mid-level power requirements, providing a nuanced and controlled audio response for a well-balanced sound profile.
Taking versatility to the next level, the NCAS1000MP features the Hypex Extension connector. This innovative addition allows for an extra, low-power 100W tweeter amplifier channel, expanding your audio setup possibilities and making it suitable for three-way loudspeakers.
Together, all channels create a synergy that elevates the overall audio performance of the NCAS1000MP. The full-bridge high-power channel tackles the heavy lifting, while the half-bridge medium-power channel handles the subtleties, and the optional NC100HF for tweeters, resulting in a harmonious blend of power and precision. This dynamic amplification duo or trio ensures that the NCAS1000MP is a versatile solution for a wide range of active speaker applications, from studio monitors to high-quality PA loudspeakers.
The NCAS1000 main SMPS consists of an active power factor corrected universal mains power supply with regulated output, delivering consistent power to the amplifiers in all operating conditions. Auxiliary power is available for external hardware e.g. DSP input cards. For added versatility, the NCAS1000MP is equipped with a low-power standby SMPS, meeting the 2013 ERP Lot 6 0.5W requirements. This feature ensures energy efficiency during idle periods, aligning with modern eco-conscious standards without compromising on performance.
Highlights
- • High efficiency
- • Universal mains operation
- • Flat, fully load independent frequency response
- • Low output impedance
- • Very low, frequency independent THD
- • Very low noise
Features
- • 5W standby SMPS
- • Advanced protections
Protections
- • Advanced overcurrent protection
- • Excessive DC protection
- • Over temperature protection
- • Short circuit protection
Possible applications
- • Monitor loudspeakers for studios
- • Active PA loudspeakers
- • Active HiFi loudspeakers
