Product information "NC400 mono kit"
*** This product is discontinued ***
The DIYclassD NC400 DIY mono block is probably the best and most easy way to get a high-end HiFi system in your livingroom. The KIT is designed with an easy to use mindset. Anyone can build it and enjoy the sound in the shortest time possible.Everything is there: A NC400, SMPS600, chassis, cables. You don't even need to solder, we did it for you.
Internal size: 193mm(W) x 58mm(H) x 265mm(D)
External size: 200mm(W) x 79mm(H) x 280mm(D) (size incl feet, excl connectors)
THIS KIT CONTAINS
- Hypex DIY mono case
- NC400
- SMPS600
- Power connector IEC 60320 C14 fused (incl. 5 AT fuses)
- Switch on-off
- Binding post clear
- Signal cable with XLR female chassis
- Internal speaker wires
- Internal mains wires
- Protective earth cable
- All needed bolts
| Output Power (2Ω): | 580W |
|---|---|
| Output Power (4Ω): | 400W |
| Output Power (8Ω): | 200W |
| Channels: | 1 |
| HxR Ready: | On board |
| SMPS Voltage +/-: | 2 x 65V |
| Compatible SMPS: | Included in kit |
| Technology: | NCORE® |
